Mineral Jig Apparatus
A Mineral Jig is a mechanical device used for separating materials of different specific gravity by the pulsation of a stream of liquid flowing through a bed of material. The setup consists of plunger operated by crank mechanism connected to motor coupled with reduction gear box. Sump tank with pump is provided for water circulation.
Technical Specification :-
• Mineral Jig Tank : Material Stainless Steel.
• Jigging arrangement : Plunger (made of Stainless steel) connected to FHP motor Coupled with reduction gear box
• Sump Tank : Material Stainless Steel, Compatible Capacity.
• Water Circulation : ½ HP Pump.
• Product Tank : Material Stainless Steel, capacity 10 ltrs (approx.), 02Nos.
• Control Panel comprises of : Standard make on off switch, Mains Indicator etc.
