Humidification & Dehumidification Apparatus
The setup consists of two glass columns with packing of rashing rings and silica gel. Water & Air flow rates can be set and measured by Rotameters and temperature by RTD type temperature sensors. Water at desired temperature is sprayed in first column. Air from compressed air supply connected to bottom of first column and air outlet from top of the first column connected to bottom of second column and then air leaves from top of the second column. Wet/Dry bulb temperatures of air line are measured from suitable locations.
Technical Specification :-
• Column : Material Borosilicate Glass Dia 50 mm, Length 500 mm (2Nos.)
• Packing : Rasching Rings & Silica Gel.
• Air Flow Measurement : By Rotameter.
• Water Flow Measurement : By Rotameter.
• Water Tank : Material Stainless Steel, compatible capacity
• Water circulation : By Pump
• Heater : Nichrome wire heater
• Condenser : Material SS, compatible capacity
• Temperature sensors : RTD PT-100 type- 10Nos.
• Control panel comprising of : Digital Temp. Controller : 0-199.9 °C, For Air Digital Temp. Indicator : 0-199.9 °C, with multi-channel switch With Standard make On/Off switch, Mains Indicator etc.
